--- title: Technical information for 55" Surface Hub ms.reviewer: manager: dansimp description: Specifications for the 55" Surface Hub ms.prod: surface-hub ms.sitesec: library author: levinec ms.author: ellevin ms.topic: article ms.localizationpriority: medium --- # Technical information for 55" Surface Hub ## Measurements | --- | --- Pricing | Starting at $8,999 Size | 31.75” x 59.62” x 3.38” (806.4mm x 1514.3mm x 85.8mm) Storage/RAM | SSD 128GB with 8GB RAM Processor | 4th Generation Intel® Core™ i5 Graphics | Intel® HD 4600 Ports | **Internal PC**
• (1) USB 3.0 (bottom) + (1) USB 3.0 (side access)
• (2) USB 2.0
• Ethernet 1000 Base-T
• DisplayPort
• Video Output
• 3.5mm Stereo Out
• RJ11 Connector for system-level control
**Alternate PC**
• (2) USB 2.0 type B output
• Connection for Camera, Sensors, Microphone, Speakers
• (1) DisplayPort Video Input
**Guest PC**
• DisplayPort Video Input
• HDMI Video Input
• VGA Video Input
• 3.5mm Stereo Input
• (1) USB 2.0 type B Touchback™ Output Sensors | (2) Passive Infrared Presence Sensors, Ambient Light Sensors Speakers | (2) Front-facing stereo speakers Microphone | High-Performance, 4-Element Array Camera | (2) Wide angle HD cameras 1080p @ 30fps Pen | (2) Powered, active, subpixel accuracy Physical side buttons | Power, Input Select, Volume, Brightness Software | Windows 10 + Office (Word, PowerPoint, Excel) What’s in the box | • Surface Hub 55”
• (2) Surface Hub Pens
• Power Cable
• Setup Guide
• Start Guide
• Safety and Warranty documents
• Wireless All-in-One Keyboard Mounting features | 4X VESA standard, 400mm x 400mm plus 1150mm x 400mm pattern, 8X M6 X 1.0 threaded mounting locations Display height from floor | Recommended height of 55 inches (139.7 cm) to center of screen Product weight | Approx. 105 lb. (47.6 kg) without accessories Product shipping weight | Approx. 150 lb. (68 kg) Product dimensions HxWxD | 31.63 x 59.62 x 3.2 inches (80.34 x 151.44 x 8.14 cm) Product shipping dimensions HxWxD | 43 x 65 x 20 inches (109 x 165 x 51 cm) Product thickness | Touch surface to mounting surface: ≤ 2.4 inches (6 cm) Orientation | Landscape only. Display cannot be used in a portrait orientation. BTU | 1706 BTU/h Image resolution | 1920 x 1080 Frame rate | 120Hz EDID preferred timing, replacement PC | 1920 x 1080, 120Hz vertical refresh EDID preferred timing, wired connect | 1920 x 1080, 60Hz vertical refresh Input voltage | (50/60Hz) 110/230v nominal, 90-265v max Input power, operating | 500W max Input power, standby | 5W nominal ## Replacement PC connections Connector and location | Label | Description --- | --- | --- Switch, bottom I/O | ![](images/switch.png) | Switches the function between using internal PC or external PC. Display port, bottom I/O | ![](images/dport.png) | Provides input for replacement PC. USB type B, bottom I/O | ![](images/usb.png) | Provides USB connection for replacement PC to internal peripherals. USB type B, bottom I/O | ![](images/usb.png) | Provides USB connection for integrated hub. ## Wired connect connections Connector and location | Label | Description --- | --- | --- Display port, bottom I/O | ![](images/dportio.png) | Provides input for wired connect PC. HDMI, bottom I/O | ![](images/hdmi.png) | Provides HDMI input for wired connect PC. VGA, bottom I/O | ![](images/vga.png) | Provides VGA input for wired connect PC. 3.5mm, bottom I/O | ![](images/35mm.png) | Provides analog audio input. USB type B, bottom I/O | ![](images/usb.png) | Provides USB connection for video ingest touchback. ## Additional connections Connector and location | Label | Description --- | --- | --- USB type A, side I/O | ![](images/usb.png) | Provides 1 USB 3.0 connection for USB devices. Wake-on USB capable. USB type A, bottom I/O with blue insulator | ![](images/usb.png) | Provides USB 3.0 connection. 3.5mm, bottom I/O | ![](images/analog.png) | Provides analog audio out. Display port, bottom I/O | ![](images/dportout.png) | Provides mirrored video out function to another display. IEC/EN60320-C13 receptacle with hard switch | ![](images/iec.png) | Provides AC input and compliance with EU power requirements. RJ45, bottom I/O | ![](images/rj45.png) | Connects to Ethernet. RJ11, bottom I/O | ![](images/rj11.png) | Connects to room control systems. ## Diagrams of ports and clearances ***Top view of 55" Surface Hub*** ![](images/sh-55-top.png) --- ***Front view of 55" Surface Hub*** ![](images/sh-55-front.png) --- ***Bottom view of 55" Surface Hub*** ![](images/sh-55-bottom.png) --- ***Replacement PC ports on 55" Surface Hub*** ![](images/sh-55-rpc-ports.png) --- ***Keypad on right side of 55" Surface Hub*** ![](images/key-55.png) --- ***Rear view of 55" Surface Hub*** ![](images/sh-55-rear.png) --- ***Clearances for 55" Surface Hub*** ![](images/sh-55-clearance.png) --- ***Front and bottom handholds and clearances for 55" Surface Hub*** ![](images/sh-55-hand.png) --- ***Rear handholds and clearances for 55" Surface Hub*** ![](images/sh-55-hand-rear.png)
