IE opens the ActiveX control’s website.
2. Download the latest version of the control.
**Security Note:**
If you don’t fully trust a site, you shouldn’t allow it to load an outdated ActiveX control. However, although we don’t recommend it, you can view the missing webpage content by tapping or clicking **Run this time**. This option runs the ActiveX control without updating or fixing the problem. The next time you visit a webpage running the same outdated ActiveX control, you’ll get the notification again.
**To get the updated app**
1. From the security warning, tap or click **Update** link.
IE opens the app’s website.
2. Download the latest version of the app.
**Security Note:**
If you don’t fully trust a site, you shouldn’t allow it to launch an outdated app. However, although we don’t recommend it, you can let the webpage launch the app by tapping or clicking **Allow**. This option opens the app without updating or fixing the problem. The next time you visit a webpage running the same outdated app, you’ll get the notification again.
## How does IE decide which ActiveX controls to block?
IE uses Microsoft’s versionlist.xml or versionlistWin7.xml file to determine whether an ActiveX control should be stopped from loading. These files are updated with newly-discovered out-of-date ActiveX controls, which IE automatically downloads to your local copy of the file.
You can see your copy of the file here `%LOCALAPPDATA%\Microsoft\Internet Explorer\VersionManager\versionlist.xml` or you can view Microsoft’s version, based on your operating system and version of IE, here:
- [Internet Explorer 11 on Windows 7 SP1 or Windows Server 2008 R2](https://go.microsoft.com/fwlink/p/?LinkId=798230)
- [All other configurations](https://go.microsoft.com/fwlink/p/?LinkId=403864)
**Security Note:**
Although we strongly recommend against it, if you don’t want your computer to automatically download the updated version list from Microsoft, run the following command from a command prompt:
```
reg add "HKCU\Software\Microsoft\Internet Explorer\VersionManager" /v DownloadVersionList /t REG_DWORD /d 0 /f
```
Turning off this automatic download breaks the out-of-date ActiveX control blocking feature by not letting the version list update with newly outdated controls, potentially compromising the security of your computer. Use this configuration option at your own risk.
## Out-of-date ActiveX control blocking on managed devices
Out-of-date ActiveX control blocking includes four new Group Policy settings that you can use to manage your web browser configuration, based on your domain controller. You can download the administrative templates, including the new settings, from the [Administrative templates (.admx) for Windows 10](https://go.microsoft.com/fwlink/p/?LinkId=746579) page or the [Administrative Templates (.admx) for Windows 8.1 and Windows Server 2012 R2](https://go.microsoft.com/fwlink/p/?LinkId=746580) page, depending on your operating system.
### Group Policy settings
Here’s a list of the new Group Policy info, including the settings, location, requirements, and Help text strings. All of these settings can be set in either the Computer Configuration or User Configuration scope, but Computer Configuration takes precedence over User Configuration.
**Important**
Out-of-date ActiveX control blocking is turned off in the Local Intranet Zone and the Trusted Sites Zone; therefore, intranet websites and line-of-business apps will continue to use out-of-date ActiveX controls without disruption.
|Setting |Category path |Supported on |Help text |
|--------|--------------|-------------|----------|
|Turn on ActiveX control logging in IE |`Administrative Templates\Windows Components\Internet Explorer\Security Features\Add-on Management` |Internet Explorer 8 through IE11 |This setting determines whether IE saves log information for ActiveX controls.
If you enable this setting, IE logs ActiveX control information (including the source URI that loaded the control and whether it was blocked) to a local file.
If you disable or don't configure this setting, IE won't log ActiveX control information.
Note that you can turn this setting on or off regardless of the **Turn off blocking of outdated ActiveX controls for IE** or **Turn off blocking of outdated ActiveX controls for IE on specific domains** settings. | |Remove the **Run this time** button for outdated ActiveX controls in IE |`Administrative Templates\Windows Components\Internet Explorer\Security Features\Add-on Management`|Internet Explorer 8 through IE11 |This setting allows you stop users from seeing the **Run this time** button and from running specific outdated ActiveX controls in IE.
If you enable this setting, users won't see the **Run this time** button on the warning message that appears when IE blocks an outdated ActiveX control.
If you disable or don't configure this setting, users will see the **Run this time** button on the warning message that appears when IE blocks an outdated ActiveX control. Clicking this button lets the user run the outdated ActiveX control once. | |Turn off blocking of outdated ActiveX controls for IE on specific domains |`Administrative Templates\Windows Components\Internet Explorer\Security Features\Add-on Management` |Internet Explorer 8 through IE11 |This setting allows you to manage a list of domains on which IE will stop blocking outdated ActiveX controls. Outdated ActiveX controls are never blocked in the Intranet Zone.
If you enable this setting, you can enter a custom list of domains for which outdated ActiveX controls won't be blocked in IE. Each domain entry must be formatted like one of the following:
If you disable or don't configure this setting, the list is deleted and IE continues to block specific outdated ActiveX controls on all domains in the Internet Zone. | |Turn off blocking of outdated ActiveX controls for IE |`Administrative Templates\Windows Components\Internet Explorer\Security Features\Add-on Management` |Internet Explorer 8 through IE11 |This setting determines whether IE blocks specific outdated ActiveX controls. Outdated ActiveX controls are never blocked in the Intranet Zone.
If you enable this setting, IE stops blocking outdated ActiveX controls.
If you disable or don't configure this setting, IE continues to block specific outdated ActiveX controls. | |Remove the **Update** button in the out-of-date ActiveX control blocking notification for IE |This functionality is only available through the registry |Internet Explorer 8 through IE11 |This setting determines whether the out-of-date ActiveX control blocking notification shows the **Update** button. This button points users to update specific out-of-date ActiveX controls in IE. | If you don't want to use Group Policy, you can also turn these settings on or off using the registry. You can update the registry manually. |Setting |Registry setting | |-------------------------|----------------------------------------------------------------| |Turn on ActiveX control logging in IE |`reg add "HKCU\Software\Microsoft\Windows\CurrentVersion\Policies\Ext" /v AuditModeEnabled /t REG_DWORD /d 1 /f`
Where:
Where:
reg add "HKCU\Software\Microsoft\Windows\CurrentVersion\Policies\Ext\Domain" /v contoso.com /t REG_SZ /fWhere:
Where:
Where:
**Note**
Enhanced Protected Mode isn’t supported on Internet Explorer 9 or earlier versions of IE. Therefore, if you’re using Internet Explorer 8 or Internet Explorer 9, all ActiveX controls will always be marked as not EPM-compatible.
- **Reason.** The ActiveX control can be blocked or allowed for any of these reasons:
|Reason |Corresponds to |Description |
|-------------------------|---------------|-------------------------------------------------|
|Version not in blocklist |Allowed |The version of the loaded ActiveX control is explicitly allowed by the IE version list. |
|Trusted domain |Allowed |The ActiveX control was loaded on a domain listed in the **Turn off blocking of outdated ActiveX controls for IE on specific domains** setting. |
|File doesn’t exist |Allowed |The loaded ActiveX control is missing required binaries to run correctly. |
|Out-of-date |Blocked |The loaded ActiveX control is explicitly blocked by the IE version list because it is out-of-date. |
|Not in blocklist |Allowed |The loaded ActiveX control isn’t in the IE version list. |
|Managed by policy |Allowed |The loaded ActiveX control is managed by a Group Policy setting that isn’t listed here, and will be managed in accordance with that Group Policy setting. |
|Trusted Site Zone or intranet |Allowed |The ActiveX control was loaded in the Trusted Sites Zone or the Local Intranet Zone. |
|Hardblocked |Blocked |The loaded ActiveX control is blocked in IE because it contains known security vulnerabilities. |
|Unknown |Allowed or blocked |None of the above apply. |
### Inventory your ActiveX controls by using a local WMI class
For Windows 10 you also have the option to log your inventory info to a local WMI class. Info logged to this class includes all of info you get from the .csv file, plus the CLSID of the loaded ActiveX control or the name of any apps started from an ActiveX control.
#### Before you begin
Before you can use WMI to inventory your ActiveX controls, you need to [download the configuration package (.zip file)](https://go.microsoft.com/fwlink/p/?LinkId=616971), which includes:
- **ConfigureWMILogging.ps1**. A Windows PowerShell script.
- **ActiveXWMILogging.mof**. A managed object file.
Before running the PowerShell script, you must copy both the .ps1 and .mof file to the same directory location, on the client computer.
**To configure IE to use WMI logging**
1. Open your Group Policy editor and turn on the `Administrative Templates\Windows Components\Internet Explorer\Turn on ActiveX control logging in IE` setting.
2. On the client device, start PowerShell in elevated mode (using admin privileges) and run `ConfigureWMILogging.ps1` by by-passing the PowerShell execution policy, using this command:
```
powershell –ExecutionPolicy Bypass .\ConfigureWMILogging.ps1
```
For more info, see [about_Execution_Policies](https://go.microsoft.com/fwlink/p/?linkid=517460).
3. **Optional:** Set up your domain firewall for WMI data. For more info, see [Collect data using Enterprise Site Discovery](collect-data-using-enterprise-site-discovery.md).
The inventory info appears in the WMI class, `IEAXControlBlockingAuditInfo`, located in the WMI namespace, *root\\cimv2\\IETelemetry*. To collect the inventory info from your client computers, we recommend using System Center 2012 R2 Configuration Manager or any agent that can access the WMI data. For more info, see [Collect data using Enterprise Site Discovery](collect-data-using-enterprise-site-discovery.md).
