Office CSP

The Office configuration service provider (CSP) enables a Microsoft Office client to be installed on a device via the Office Deployment Tool (ODT). For more information, see Configuration options for the Office Deployment Tool and How to assign Office 365 apps to Windows 10 devices with Microsoft Intune.

This CSP was added in Windows 10, version 1703.

For additional information, see Office DDF.

The following diagram shows the Office configuration service provider in tree format.

./Device/Vendor/MSFT/Office/ or ./User/Vendor/MSFT/Office
The root node for the Office configuration service provider.

Installation
Specifies the options for the Microsoft Office installation.

The supported operations are Add, Delete, and Get.

Installation/id
Specifies a unique identifier that represents the ID of the Microsoft Office product to install.

The supported operations are Add, Delete, and Get.

Installation/id/Install
Installs Office by using the XML data specified in the configuration.xml file.

The supported operations are Get and Execute.

Installation/id/Status
The Microsoft Office installation status.

The only supported operation is Get.

Installation/id/FinalStatus
Added in Windows 10, version 1809. Indicates the status of the Final Office 365 installation.

The only supported operation is Get.

Behavior:

• When Office CSP is triggered to install, it will first check if the FinalStatus node exists or not. If the node exists, delete it.
• When Office installation reaches any terminal states (either success or failure), this node is created that contains the following values:
  • When status = 0: 70 (succeeded)
  • When status != 0: 60 (failed)

Installation/CurrentStatus
Returns an XML of current Office 365 installation status on the device.

The only supported operation is Get.

Examples

Sample SyncML to install Microsoft 365 Apps for business Retail from current channel.

<SyncML xmlns="SYNCML:SYNCML1.2">
  <SyncBody>
    <Exec>
      <CmdID>7</CmdID>
        <Item>
          <Target>
            <LocURI>./Vendor/MSFT/Office/Installation/0AA79349-F334-4859-96E8-B4AB43E9FEA0/install</LocURI>
          </Target>
          <Meta>
            <Format xmlns="syncml:metinf">chr</Format>
          </Meta>
          <Data>&lt;Configuration&gt;&lt;Add OfficeClientEdition=&quot;32&quot; Channel=&quot;Current&quot;&gt;&lt;Product ID=&quot;O365BusinessRetail&quot;&gt;&lt;Language ID=&quot;en-us&quot; /&gt;&lt;/Product&gt;&lt;/Add&gt;&lt;Display Level=&quot;None&quot; AcceptEULA=&quot;TRUE&quot; /&gt;&lt;/Configuration&gt;</Data>
        </Item>
    </Exec>
    <Final/>
  </SyncBody>
</SyncML>

To uninstall the Office 365 from the system:

<SyncML xmlns="SYNCML:SYNCML1.2">
  <SyncBody>
    <Exec>
      <CmdID>7</CmdID>
        <Item>
          <Target>
            <LocURI>./Vendor/MSFT/Office/Installation/E24B23D8-94A8-4997-9E6E-8FF25025845B/install</LocURI>
          </Target>
          <Meta>
            <Format xmlns="syncml:metinf">chr</Format>
          </Meta>
          <Data>&lt;Configuration&gt;&lt;Remove All=&quot;TRUE&quot;/&gt;&lt;Display Level=&quot;None&quot; AcceptEULA=&quot;TRUE&quot; /&gt;&lt;/Configuration&gt;</Data>
        </Item>
    </Exec>
    <Final/>
  </SyncBody>
</SyncML>

To get the current status of Office 365 on the device.

<SyncML xmlns="SYNCML:SYNCML1.2">
  <SyncBody>
    <Get>
      <CmdID>7</CmdID>
        <Item>
          <Target>
            <LocURI>./Vendor/MSFT/Office/Installation/CurrentStatus</LocURI>
          </Target>
        </Item>
    </Get>
    <Final/>
  </SyncBody>
</SyncML>

Status code

Status	Description	Comment
0	Installation succeeded	OK
997	Installation in progress
13	ERROR_INVALID_DATA Cannot verify signature of the downloaded Office Deployment Tool (ODT)	Failure
1460	ERROR_TIMEOUT Failed to download ODT	Failure
1602	ERROR_INSTALL_USEREXIT User cancelled the installation	Failure
1603	ERROR_INSTALL_FAILURE Failed any pre-req check. SxS (Tried to install when 2016 MSI is installed) Bit mismatch between the currently installed Office and the Office that was attempting to be installed (such as when you try to install a 32-bit version while 64-bit version is currently installed.)	Failure
17000	ERROR_PROCESSPOOL_INITIALIZATION Failed to start C2RClient	Failure
17001	ERROR_QUEUE_SCENARIO Failed to queue installation scenario in C2RClient	Failure
17002	ERROR_COMPLETING_SCENARIO Failed to complete the process. Possible reasons: Installation cancelled by user Installation cancelled by another installation Out of disk space during installation Unknown language ID	Failure
17003	ERROR_ANOTHER_RUNNING_SCENARIO Another scenario is running	Failure
17004	ERROR_COMPLETING_SCENARIO_NEED_CLEAN_UP Possible reasons: Unknown SKUs Content does't exist on CDN such as trying to install an unsupported LAP, like zh-sg CDN issue that content is not available Signature check issue, such as failed the signature check for Office content User cancelled	Failure
17005	ERROR_SCENARIO_CANCELLED_AS_PLANNED	Failure
17006	ERROR_SCENARIO_CANCELLED Blocked update by running apps	Failure
17007	ERROR_REMOVE_INSTALLATION_NEEDED The client is requesting client clean up in a "Remove Installation" scenario	Failure
17100	ERROR_HANDLING_COMMAND_LINE C2RClient command line error	Failure
0x80004005	E_FAIL ODT cannot be used to install Volume license	Failure
0x8000ffff	E_UNEXPECTED Tried to uninstall when there is no C2R Office on the machine.	Failure
