Technical information for 55" Surface Hub

Measurements


Pricing	Starting at $8,999
Size	31.75” x 59.62” x 3.38” (806.4mm x 1514.3mm x 85.8mm)
Storage/RAM	SSD 128GB with 8GB RAM
Processor	4th Generation Intel® Core™ i5
Graphics	Intel® HD 4600
Ports	Internal PC • (1) USB 3.0 (bottom) + (1) USB 3.0 (side access) • (2) USB 2.0 • Ethernet 1000 Base-T • DisplayPort • Video Output • 3.5mm Stereo Out • RJ11 Connector for system-level control Alternate PC • (2) USB 2.0 type B output • Connection for Camera, Sensors, Microphone, Speakers • (1) DisplayPort Video Input Guest PC • DisplayPort Video Input • HDMI Video Input • VGA Video Input • 3.5mm Stereo Input • (1) USB 2.0 type B Touchback™ Output
Sensors	(2) Passive Infrared Presence Sensors, Ambient Light Sensors
Speakers	(2) Front-facing stereo speakers
Microphone	High-Performance, 4-Element Array
Camera	(2) Wide angle HD cameras 1080p @ 30fps
Pen	(2) Powered, active, subpixel accuracy
Physical side buttons	Power, Input Select, Volume, Brightness
Software	Windows 10 + Office (Word, PowerPoint, Excel)
What’s in the box	• Surface Hub 55” • (2) Surface Hub Pens • Power Cable • Setup Guide • Start Guide • Safety and Warranty documents • Wireless All-in-One Keyboard
Mounting features	4X VESA standard, 400mm x 400mm plus 1150mm x 400mm pattern, 8X M6 X 1.0 threaded mounting locations
Display height from floor	Recommended height of 55 inches (139.7 cm) to center of screen
Product weight	Approx. 105 lb. (47.6 kg) without accessories
Product shipping weight	Approx. 150 lb. (68 kg)
Product dimensions HxWxD	31.63 x 59.62 x 3.2 inches (80.34 x 151.44 x 8.14 cm)
Product shipping dimensions HxWxD	43 x 65 x 20 inches (109 x 165 x 51 cm)
Product thickness	Touch surface to mounting surface: ≤ 2.4 inches (6 cm)
Orientation	Landscape only. Display cannot be used in a portrait orientation.
BTU	1706 BTU/h
Image resolution	1920 x 1080
Frame rate	120Hz
EDID preferred timing, replacement PC	1920 x 1080, 120Hz vertical refresh
EDID preferred timing, wired connect	1920 x 1080, 60Hz vertical refresh
Input voltage	(50/60Hz) 110/230v nominal, 90-265v max
Input power, operating	500W max
Input power, standby	5W nominal

Replacement PC connections

Connector and location	Label	Description
Switch, bottom I/O		Switches the function between using internal PC or external PC.
Display port, bottom I/O		Provides input for replacement PC.
USB type B, bottom I/O		Provides USB connection for replacement PC to internal peripherals.
USB type B, bottom I/O		Provides USB connection for integrated hub.

Wired connect connections

Connector and location	Label	Description
Display port, bottom I/O		Provides input for wired connect PC.
HDMI, bottom I/O		Provides HDMI input for wired connect PC.
VGA, bottom I/O		Provides VGA input for wired connect PC.
3.5mm, bottom I/O		Provides analog audio input.
USB type B, bottom I/O		Provides USB connection for video ingest touchback.

Additional connections

Connector and location	Label	Description
USB type A, side I/O		Provides 1 USB 3.0 connection for USB devices. Wake-on USB capable.
USB type A, bottom I/O with blue insulator		Provides USB 3.0 connection.
3.5mm, bottom I/O		Provides analog audio out.
Display port, bottom I/O		Provides mirrored video out function to another display.
IEC/EN60320-C13 receptacle with hard switch		Provides AC input and compliance with EU power requirements.
RJ45, bottom I/O		Connects to Ethernet.
RJ11, bottom I/O		Connects to room control systems.
