Add a Windows 10 operating system image using Configuration Manager

Applies to

Windows 10

Operating system images are typically the production image used for deployment throughout the organization. This topic shows you how to add a Windows 10 operating system image created with Microsoft Endpoint Configuration Manager, and how to distribute the image to a distribution point.

Infrastructure

For the purposes of this guide, we will use one server computer: CM01.

CM01 is a domain member server and Configuration Manager software distribution point. In this guide CM01 is a standalone primary site server.
CM01 is running Windows Server 2019. However, an earlier, supported version of Windows Server can also be used.

An existing Configuration Manager infrastructure that is integrated with MDT is used for the following procedures. For more information about the setup for this article, see Prepare for Zero Touch Installation of Windows 10 with Configuration Manager.

Important

The procedures in this article require a reference image. Our reference images is named REFW10-X64-001.wim. If you have not already created a reference image, then perform all the steps in Create a Windows 10 reference image on CM01, replacing MDT01 with CM01. The final result will be a reference image located in the D:\MDTBuildLab\Captures folder that you can use for the procedure below.
